BalloonTick
Drawing ballooning & first article inspection

Balloon a drawing and finish the inspection report in your browser

Open a PDF drawing, number every characteristic, type the measured results and export the ballooned PDF and an Excel report laid out in the style of AS9102 Forms 1, 2 and 3. Nothing to install, on any computer.

Your drawings never leave your computer.Everything runs in your browser; the drawing is not uploaded to our server and we never store it. How that works.
Nothing to installWindows, Mac, Linux, ChromebookDrawings stay on your computerFrom $25 a drawing, no licence fee

Everything an inspector needs, in one page

Built for quality inspectors at machine shops and contract manufacturers who supply aerospace, defense, automotive and medical device companies.

Suggested balloons from PDF text

Finds dimensions, tolerances, GD&T frames, threads, chamfers and notes in PDFs exported from CAD, including vertical text, and pre-fills the values for you to accept.

Click to balloon anything

Place, drag and renumber balloons with leaders. Circle, hexagon, square, diamond or triangle; any size and colour. Typing a used number moves the others up.

Limits, units and sub-numbers

Upper and lower limits from ± or stacked tolerances, inch and mm side by side, title-block default tolerances, and 4X dimensions split into 12.1 to 12.4.

Pass or fail as you type

Enter results for one part or a sample of up to ten; each result turns PASS or FAIL against its limits. Paste a column of results straight from Excel or a CMM report.

Reports your customer expects

Excel laid out in the style of AS9102 Forms 1, 2 and 3, a PPAP-style dimensional results sheet, a CSV for your own template, and the ballooned PDF with vector balloons.

Revisions without starting over

Open the new revision into the same project: balloons stay where they were, changed text is flagged, and every characteristic is re-confirmed before export.

No wrong number goes out unchecked

Reading values from a drawing automatically is never perfect, in any software. So BalloonTick never exports a value you have not confirmed: every suggested value is marked until you tick it, and duplicated or missing balloon numbers block the export. There is no "export anyway".

Open the drawing

PDF (any number of sheets), PNG, JPG or TIFF. It opens in your browser.

Balloon it

Accept the suggested balloons, or click each feature. Adjust numbers, shapes and leaders.

Check and measure

Confirm each requirement against the drawing, then type the measured results.

Export

Ballooned PDF, Excel report and CSV. One credit covers all of them for 7 days.

Compared with desktop ballooning software

BalloonTickTypical desktop software
InstallNone, runs in the browserWindows installer, licence key
Where the drawing goesStays on your computerYour computer (cloud products upload it)
Price to start$25 for one drawing, or $49 a monthOften $1,000+ per seat, or a yearly subscription
Free to tryBalloon and preview any drawing, no time limitUsually a 14 to 30 day trial
Unconfirmed valuesExport blocked until confirmedVaries

Questions

Is my drawing uploaded to your server?

No. BalloonTick opens the drawing in your browser and every step (viewing, ballooning, reading text, building the PDF and Excel files) runs on your computer. The drawing is never sent to our server and we never store it. When you export, the only thing sent is a fingerprint of the file (a SHA-256 hash, which cannot be turned back into the drawing) so one credit covers every export of that drawing for 7 days.

Does it read the dimensions automatically?

For PDF drawings that contain real text (most PDFs exported from CAD), BalloonTick suggests balloons where it finds dimensions, tolerances, GD&T frames, threads and notes, and pre-fills the values. Nothing is added until you accept it, and every suggested value stays marked until you tick it as checked against the drawing. Scanned drawings and images are ballooned by clicking; the values are typed by you.

What do I get in the export?

The ballooned drawing as a PDF (balloons added on top of the original page, which stays sharp vector), an Excel report with three sheets laid out in the style of AS9102 Forms 1, 2 and 3, and a CSV of the characteristics. BalloonTick is not certified by or affiliated with SAE International or the IAQG; check the report against your customer's requirements.

What is free?

Opening a drawing, placing balloons, filling in the table, typing measured results and previewing the report on screen. You need a credit or a plan only to export the files.

How do credits work?

One credit covers every export of one drawing (ballooned PDF, Excel and CSV) for 7 days, so correcting a value and exporting again costs nothing. A single credit is $25. Pack credits do not expire. Plans include a number of drawings each month.

Can I save my work and come back later?

Yes. Save project writes one file to your computer with the drawing, the balloons and the table. Open it again later, on any computer. Because we never store drawings, that file is your copy; keep it with the job.

All questions

Balloon your next drawing in minutes

Free to open, balloon and preview. Pay only when you export.

Open a drawing
